RK1302 Mbinu ya juu ya Bluetooth RFID Scanner inaweza kujengwa katika msomaji wa barcode 1D / 2D kwa usimamizi wa ghala

Kitambulisho cha Bidhaa: RK1302

Ufungaji na Utoaji

Ufungaji Maelezo ya kificho ya barcode

Muda wa Utoaji Siku 7 za kazi baada ya malipo

Sambamba OS: Android, Windows, Linux

Miradi: Usimamizi wa ghala, Logistiscs.Medical Management, Express Viwanda

Mbinu ya juu ya Bluetooth RFID Scanner inaweza kujengwa katika msomaji wa barcode 1D / 2D kwa usimamizi wa ghala

Product Parameter

Light source red	5600K LEDs (illumination illumination) LED 625 ± 10nm (aim aimer)
Image Sensor	640 x 480 CMOS
Processor	ARM32-bit
Resolution	≥4mil/0.1mm（PCS90%,CODE 39）
Read depth of field	10mm~650mm
Reading mode	induction reading /manual reading
Prompt mode	Buzzer/ LED
Read angle	Test Conditions：CODE39,10mil/0.25mm,PCS90%
	Rotate Roll: ± 360 °, tilt Pitch: ± 55 °, skew Skew: ± 50 °
Print contrast	≥25%
Ambientintensity	0-10000LUX light
Reading code system	1D：UPC-A，UPC-E，EAN-8，EAN-13， Code 128， GS1-128， Code 39，Code 93，Code 11，Interleaved 2 of 5，Matrix 2 of 5，Codabar（NW-7），MSI， etc. 2D: QR Code，PDF417，Data Matrix，etc.

Mechanical / electrification performance

Working Temp	-20℃ to 50℃
Storage Temp	-40℃ to 70℃
Work humidity	5% to 95%（No condensation）
Protection class	IP42
Drop Test	1.5m，100 times
High and low temperature test	30 minutes for high Temp., 30 minutes for low Temp.,
High temperature	60℃
Low	-20℃
Transport vibration test	10H@125RPM

Data lines	USB data cable for connecting the host terminal
	RS232 data cable for connecting the host terminal with a power adapter DC connector
Power adapter (optional)	Output：DC 5V, 1A；Input： AC 100~240V, 50~60Hz

Test conditions: room temperature 25 ℃, ambient illumination 200LUX, PCS = 0.9

High quality Bluetooth RFID Scanner can buit-in 1D/ 2D barcode reader for warehouse management
